Laser/ILCA Spars Rivets List

Laser/ILCA Spars Rivets List

The ultimate riveting guide for your Laser® /ILCA spars!

Upper Mast Section

Upper Mast Base Plug 2 x 4.8mm (3/16") x 12mm s/s rivet
Upper Mast Top Plug 1 x 4.8mm (3/16") x 12mm s/s rivet
Upper Mast Sleeve 1 x 4.8mm (3/16") x 16mm s/s rivet

Lower Mast Section

Lower Mast Plug 1 x 4.8mm (3/16") x 12mm c/s aluminum rivet
Kicker Tang 4 x 4.8mm (3/16") x 12mm s/s rivet
Gooseneck 6 x 4.8mm (3/16") x 12mm s/s rivet

Boom

Gooseneck Plug 2 x 4.8mm (3/16") x 12mm s/s rivet
Boom Kicker Bracket 4 x 4.8mm (3/16") x 16mm s/s rivet
Mainsheet block lacing eye 4 x 4.8mm (3/16") x 16mm s/s rivet
Clamcleat 2 x 4.8mm (3/16") x 16mm s/s rivet
Soft fairlead 1 x 4.8mm (3/16") x 12mm s/s rivet
Fairlead 2 x 4.8mm (3/16") x 16mm s/s rivet



Rooster Laser/ILCA Tiller

The RWO plastic trap fitting as used on the Rooster Laser/ILCA tiller uses

2 x 4.8mm (3/16") x 14mm carbon rivets

Don't forget the Duralac - a joining compound used between rivets and spars that prevents corrosion by inhibiting electrolytic corrosion between dissimilar metals. READ: Steve's riveting blog :lol: Save Save Save Save
